Semi-automatic Print Machine for SMT Production Line

Semi-automatic Print Machine for SMT Production Line

Category

Description

Applied Physics Semiconductor T3040 Stencil Printer

The Applied Physics Semiconductor T3040 Stencil Printer is engineered for high-precision solder paste applications in modern electronics manufacturing environments. Designed to meet the rigorous demands of semiconductors, automotive, aerospace, and medical device assembly, the T3040 delivers exceptional accuracy, repeatability, and ease of use. This manual stencil printer is ideal for both prototyping and high-mix/low-volume production, supporting a wide range of PCB sizes and thicknesses.

With a robust construction featuring a high-quality aluminum honeycomb platform and a thick steel plate welded base, the T3040 ensures stability and durability for consistent, reliable performance. Its user-friendly design, combined with advanced adjustment features, makes it a preferred choice for engineers and production teams seeking to optimize yield and streamline their SMT assembly processes.

Key Features

  • High-Precision Printing: Achieve repeat accuracy of ±0.01 mm for fine-pitch and microelectronics applications.
  • Versatile PCB Support: Accommodates PCB thicknesses from 0 to 80 mm and net frame sizes up to 370 × 470 mm.
  • User-Friendly Operation: Manual operation with intuitive adjustment mechanisms for horizontal angle and worktable position.
  • Robust Build Quality: Constructed with a high-quality aluminum honeycomb platform and a thick steel plate welded base for maximum stability.
  • Flexible Positioning: Supports both benchmark and hole shape positioning methods for diverse assembly requirements.
  • Comprehensive Accessories: Includes fixed links, positioning holders, fixing plates, and a complete tool set for immediate deployment.
  • Global Compliance: Certified to meet international quality and safety standards (certification details available upon request).
  • Warranty & Support: Backed by a 1-year warranty and lifelong service support from Applied Physics Semiconductor.

Technical Specifications

Specification Value / Description
Print Size 250 × 400 mm
Work Table Size 300 × 400 mm
Max Net Frame Size 370 × 470 mm
Printer Operation Manual
PCB Thickness Supported 0–80 mm
Printing Platform Height 220 mm
Worktable Adjustment 10 mm, Horizontal Angle adjustable
Repeat Accuracy ±0.01 mm
Positioning Method Benchmark or hole shape
Material High-quality aluminum honeycomb platform, thick steel plate welded base
Machine Dimensions 540 × 370 × 350 mm
Packing Size 630 × 450 × 480 mm
Net Weight 22–25 kg
Gross Weight 35 kg
Accessories Fixed link (30 pcs), positioning holder (4 pcs), fixing plate (2 pcs), tool set
Warranty 1 year, with lifelong service support
Certifications Available (details on request)

Packing & Delivery

  • Secure Packaging: Each T3040 Stencil Printer is carefully packed to ensure safe delivery.
  • Fast Shipping: Expedited delivery options available across the United States and North America.
  • Global Reach: Applied Physics Semiconductor supports international shipping and logistics.

Why Choose Applied Physics Semiconductor?

Applied Physics Semiconductor is a leading innovator in electronics manufacturing equipment, offering advanced solutions for the semiconductor industry. With over a decade of experience in research, development, and manufacturing, we deliver products that combine precision engineering, reliability, and comprehensive support. Our T3040 Stencil Printer is trusted by electronics manufacturers worldwide for its performance, durability, and ease of integration into existing SMT production lines.
